Description

The GE Fanuc IC697CGR772 is a Hot Standby Dual Bus CPU module used for high-availability control in redundancy applications, supporting real-time control with fault tolerance.

System Features

• Model: IC697CGR772

• Manufacturer: GE Fanuc

• Type: Hot Standby Dual Bus CPU

• Slot Usage: Occupies 1 slot in the Genius Series rack

• Programming Interface: MS-DOS-based software, remote operation supported

Power & Memory

• Power Supply: 5 VDC (isolated source), lithium battery backup

• Memory: 512 KB battery-backed CMOS RAM

• Battery Management: New battery must be installed before removing the old one to avoid data loss

Connectivity

• Serial Ports: 3 ports accessible from the front panel

• Status LEDs: 7 status LEDs, including battery and CPU status

Configuration & Protection

• Switch: 3-position mode switch with memory protection

• Data Locking: Can be locked via password or memory protect keyswitch
