Overview
The Triconex 3805H Analog Output Module is engineered to provide accurate and deterministic analog control signals in safety-critical environments. Each of its 8 channels is electrically isolated and independently configurable, supporting output ranges such as 4–20 mA for standard industrial actuators and control valves.
Moreover, the 3805H is fully compatible with Tricon and Trident safety systems, integrating seamlessly into Triple Modular Redundancy (TMR) architectures. It features built-in diagnostics, including open-circuit detection and loop integrity monitoring, ensuring continuous feedback on system health. For instance, in a chemical plant, the 3805H can precisely modulate valve positions based on control logic while simultaneously reporting signal integrity to the controller.
In addition, the module is hot-swappable, allowing maintenance without system shutdown. Its robust design and compliance with IEC 61508 make it suitable for SIL 3-certified safety instrumented functions (SIFs).
Technical Data
| Attribute | Specification |
|---|---|
| Model Number | 3805H |
| Product Type | Analog Output Module |
| Operating Temperature | –20°C to +60°C |
| Dimensions | 400 × 160 × 80 mm |
| Weight | 3 kg |
Typical Applications
-
Emergency Shutdown Systems (ESD): Sends analog control signals to actuators and dampers during critical events.
-
Turbine and Compressor Control: Modulates fuel valves and guide vanes based on real-time process feedback.
-
Chemical Processing Plants: Controls flow, pressure, and temperature loops with high precision.
-
Power Generation Facilities: Interfaces with boiler and turbine control systems for analog regulation.
-
Oil and Gas Platforms: Drives analog actuators in hazardous and offshore environments.
Example: In a refinery’s SIS, the 3805H module outputs a 4–20 mA signal to a control valve, adjusting flow rate based on sensor feedback while continuously verifying loop integrity.
FAQ
Q: What is the function of the Triconex 3805H module?
A: It provides 8 isolated analog output channels for precise current-based control in safety systems.
Q: Is it compatible with TMR architectures?
A: Yes, it integrates with Triconex’s Triple Modular Redundancy systems for fault-tolerant operation.
Q: What kind of diagnostics does it support?
A: It includes open-circuit detection and loop integrity monitoring for each output channel.
Q: Can it be replaced during operation?
A: Yes, it is hot-swappable, allowing maintenance without interrupting system function.
Q: What safety standards does it meet?
A: It complies with IEC 61508 and is certified for SIL 3-rated applications.
