š§ Product Overview
TheĀ Honeywell 51306856-175, comprising theĀ 8C-TDIL01 logic moduleĀ and theĀ 8U-TDIL01 IOTA (Input/Output Terminal Assembly), is aĀ high-performance digital input moduleĀ designed forĀ Honeywellās C300 ControllerĀ within theĀ Experion PKSĀ andĀ TPS distributed control systems.
This module providesĀ 16 optically isolated digital input channels, enablingĀ precise acquisition of discrete signalsĀ from field devices such as switches, sensors, and contact closures. Its robust isolation and fast response time make it ideal forĀ mission-critical applicationsĀ inĀ refining, chemical processing, power generation, andĀ pharmaceutical automation.
āļø Technical Specifications
| Specification | Details |
|---|---|
| Manufacturer | Honeywell |
| Model Number | 51306856-175 (8C-TDIL01 / 8U-TDIL01) |
| Product Type | Digital Input Module |
| Input Channels | 16 independent channels |
| Rated Input Voltage | 24 VDC |
| Input Voltage Range | 18ā30 VDC |
| Input Current | Max 6 mA per channel |
| Response Time | < 8 ms |
| Isolation Voltage | 1500 VAC |
| Power Consumption | Max 3.2 W |
| Operating Temperature | ā40Ā°C to +70Ā°C |
| Storage Temperature | ā40Ā°C to +85Ā°C |
| Humidity | 5% to 95%, non-condensing |
| Mounting | DIN rail compatible |
| Dimensions (Logic Module) | 20.2 cm Ć 14.4 cm Ć 4.9 cm |
| Dimensions (IOTA) | 118 mm Ć 32 mm Ć 87 mm |
| Weight | ~0.31 kg (Logic Module), ~140 g (IOTA) |
| Certifications | CE, UL508, CSA, TUV |
| Warranty | 12 months |
| Country of Origin | USA |
š Key Features
-
š”ļøĀ Optocoupler Isolation: Protects control systems from electrical noise and transient surges
-
ā”Ā Fast Response Time: <8 ms ensures real-time signal acquisition for time-sensitive processes
-
š§±Ā Modular Architecture: Separates logic and IOTA for flexible installation and maintenance
-
š§Ā DIN Rail Mounting: Simplifies integration into industrial control panels
-
š§ Ā C300 Controller Compatibility: Seamless operation within Honeywellās Experion PKS platform
