Overview
The ABB AI563 is part of the S500 I/O series within the AC500 PLC family, designed to provide reliable analog input functionality for industrial automation systems. It offers 8 analog input channels configurable for voltage, current, or RTD (Resistance Temperature Detector) signals, making it highly versatile for process monitoring and control. Compact and rugged, the AI563 integrates seamlessly with ABB’s AC500 PLC platform, ensuring dependable performance in demanding industrial environments.
Technical Data
| Parameter | Specification |
|---|---|
| Manufacturer | ABB |
| Model Number | AI563 |
| Product Type | Analog Input Module |
| Dimensions (W × H × D) | 67.5 × 76 × 62 mm |
| Net Weight | 0.12 kg |
| Operating Temperature | –25 °C to +70 °C |
Key Features
-
8 configurable analog input channels for voltage, current, or RTD signals
-
High accuracy (12‑bit resolution) for precise measurement
-
Supports standard industrial ranges (±10 V, 0–20 mA, 4–20 mA)
-
RTD compatibility for temperature measurement (PT100/PT1000)
-
Compact DIN rail design for easy installation
-
XC version available for extreme ambient conditions
-
Part of ABB’s AC500 PLC / S500 I/O system
Typical Applications
-
Process automation requiring analog signal monitoring
-
Temperature measurement using RTD sensors
-
Energy and power generation monitoring systems
-
Manufacturing and robotics requiring precise analog input
-
Marine and transportation automation solutions
FAQ
Q1: What is the primary function of the ABB AI563?
A1: It provides 8 analog input channels for voltage, current, or RTD signals.
Q2: What types of signals are supported?
A2: Voltage (±10 V), current (0–20 mA / 4–20 mA), and RTD (PT100/PT1000).
Q3: Can it be used in extreme environments?
A3: Yes, ABB offers an XC version designed for harsh ambient conditions.
Q4: How is it installed?
A4: It uses DIN rail mounting, making installation quick and secure.
Q5: What PLC family does it belong to?
A5: It is part of the ABB AC500 PLC / S500 I/O system.
