Product Overview
The ABB AX 722F A2 with part number 3BDH000377R0001 is a high-density, configurable Analog Input/Output (I/O) module. It is a key component of the S700 I/O series, designed to work seamlessly with ABB’s Freelance Distributed Control System (DCS) controllers, specifically the AC 700F and AC 900F.
This single module provides a versatile mix of 8 analog inputs and 8 analog outputs, making it highly flexible for a wide range of industrial automation applications. The combined I/O design saves valuable space in control cabinets while simplifying system wiring. Additionally, the AX 722F A2 can operate as direct I/O for its parent controllers or function as a PROFIBUS remote I/O, supporting diverse system architectures.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | AX 722F A2 |
| Part Number | 3BDH000377R0001 |
| Total Channels | 16 (8 analog inputs, 8 analog outputs) |
| Analog Inputs | 8 channels, individually configurable for: • Voltage: ±10 V, 0–10 V • Current: 0–20 mA, 4–20 mA • Temperature: Pt100, Pt1000, Ni1000 |
| Analog Outputs | 8 channels: • 4 AO configurable for voltage/current (±10 V, 0–20 mA, 4–20 mA) • 4 AO fixed voltage (±10 V) |
| Resolution | 12 bits plus sign |
| Power Consumption | 5 W |
| Weight | 300 g |
| Dimensions (W×H×D) | 67.5 mm × 76 mm × 54 mm |
| Quick Quotes | Receive price & availability FAST from our dedicated customer service team. |
|---|---|
| Delivery | Expedited, Freight, And International Shipping Available. |
| Condition | 100% New with Original Package |
| Payment | We accept American Express, Discover, MasterCard, PayPal, and Visa. Our site is secured by RapidSSL. |
| Shipping Port | ShangHai, Xiamen |
| Warranty | 12 Months |
