Product Description
The AAI543-S53/K4A00 is a ruggedized, high-performance 16-channel analog output module for Yokogawa Centum VP and CS 3000 Distributed Control Systems (DCS). Designed for harsh industrial environments, this module delivers precise 4–20 mA signals to field actuators, valve positioners, and other final control elements.
The S53 designation highlights its ISA Standard G3 conformal coating for corrosion resistance and an extended operating temperature range of -20°C to +70°C, making it suitable for extreme conditions such as offshore platforms, chemical plants, and outdoor control cabinets.
Equipped with the factory-installed /K4A00 KS Cable Interface Adapter (ATK4A-00), the module supports high-density wiring to AEA4D terminal boards using dedicated KS1 cables. Combined with a 10 ms data refresh cycle and 1500 V AC isolation, the AAI543-S53/K4A00 ensures fast, accurate, and secure signal transmission for critical process loops.
Technical Specifications
| Parameter | Specification |
|---|---|
| Output Channels | 16 channels, fully isolated |
| Output Signal Range | 4–20 mA DC |
| Environmental Protection | ISA G3 Conformal Coating (S53 variant) |
| Operating Temperature | -20°C to +70°C (extended range) |
| Interface Hardware | KS Cable Interface Adapter (K4A00) |
| Data Update Rate | 10 ms |
| Output Accuracy | ±48 µA |
| Load Resistance | 0–750 Ω |
| Isolation Strength | 1500 V AC (output-to-system, 1 min) |
| Fail-Safe Feature | Open-circuit detection (< 0.65 mA) |
| Power Consumption | 230 mA (5 V DC); 540 mA (24 V DC) |
| Redundancy Support | Standard switch-over response (dual-redundant capable) |
Module Durability and Application
-
Corrosion resistance: G3 conformal coating protects against gases like H₂S and SO₂.
-
Wide-temperature operation: Functions reliably in extreme climates without active cooling.
-
Compact, high-density wiring: The /K4A00 adapter simplifies cabinet installation and reduces wiring errors.
-
Redundancy capable: Ensures uninterrupted control in critical loops when paired in dual-redundant FIO configurations.
Frequently Asked Questions
Q: Does this module support HART communication?
A: No. The S53 is a standard analog output module. For HART digital pass-through, use the AAI543-H series.
Q: What is the advantage of the /K4A00 adapter?
A: It enables plug-and-play connection to terminal boards via KS1 cables, reducing manual wiring errors and shortening commissioning time.
Q: Can this module be installed in hazardous areas?
A: No. This model is designed for non-explosion protected zones. For hazardous area installations, specify the corresponding Ex-rated variant.
