Product Overview
The Bently Nevada 3300/40-13-01-01-00-00 is a critical component of the Bently Nevada 3300 Series, specifically designed to monitor the eccentricity of a rotating shaft. By utilizing a pair of proximity probes, this module measures the peak-to-peak amplitude of shaft motion. This motion is indicative of the mechanical and electrical center of the shaft. The 3300/40 is an ideal solution for monitoring large steam turbines and generators, where eccentricity is a key indicator of potential mechanical issues.
The module provides early warning of problems such as shaft bow, misalignment, and foundation issues, which can significantly impact machinery performance and reliability. By detecting these issues early, the 3300/40 helps prevent catastrophic failures and unplanned downtime.
Key Features
-
Eccentricity Monitoring: Continuously measures the eccentricity of rotating shafts.
-
Proximity Probe Inputs: Uses two Proximity Probe/Proximitor systems to monitor shaft motion.
-
Early Detection of Mechanical Issues: Ideal for identifying shaft bow, misalignment, and foundation problems.
-
Real-Time Outputs: Provides recorder outputs (4-20 mA or 0 to -10 Vdc) for further analysis.
-
Dual Relay Alarm: Offers dual relay alarm options (Non-Epoxy sealed) for proactive maintenance.
Technical Specifications
| Parameter | Details |
|---|---|
| Model Number | 3300/40-13-01-01-00-00 |
| Product Type | Eccentricity Monitor Module |
| Series | 3300/40 |
| Number of Channels | 2 |
| Weight | 1.65 kg |
| Operating Temperature | 0°C to +65°C |
| Storage Temperature | -40°C to +85°C |
| Quick Quotes | Receive price & availability FAST from our dedicated customer service team. |
|---|---|
| Delivery | Expedited, Freight, And International Shipping Available. |
| Condition | 100% New with Original Package |
| Payment | We accept American Express, Discover, MasterCard, PayPal, and Visa. Our site is secured by RapidSSL. |
| Shipping Port | ShangHai, Xiamen |
| Warranty | 12 Months |
| Q: Is Our Pricing Competitive? |
| A: Yes, we collaborate with over 50 countries worldwide. As a top supplier in China, we offer significant discounts based on market trends. |
| Q: What Is the Warranty Period? |
| A: All our new and original products come with a standard one-year warranty. |
| Q: What Payment Methods Do We Accept? |
| A: We require 100% T/T (Telegraphic Transfer) payment before shipping. For items with a lead time, a 30% deposit is needed upfront, and the remaining 70% is due before shipping. If you have a representative in China, you can arrange an RMB transfer through them. |
| Q: What Shipping Methods Do We Use? |
| A: We primarily use FedEx, DHL, UPS, and BRE for shipping. If you have an account with any of these carriers, you can handle shipping directly. We also offer free shipping to China-based freight forwarders. |
| Q: What Is Our Delivery Time? |
| A: Delivery usually takes 1-3 days after receiving the initial payment. For items with a lead time, shipping will occur according to the specified schedule. |
| Q: How Do We Package the Goods? |
| A: We ensure safe packaging with multiple layers of protection. Products are first placed in their original boxes and sealed with labels. A layer of bubble wrap is then added for collision protection during transit. Finally, the items are packed securely in durable boxes. |
| Q: How Can Customers Contact Us and Request a Quote? |
| A: You can reach out to us via email, WhatsApp, WeChat, Skype, or your preferred communication platform. Contact us with your needs, and we'll provide a prompt, customized quote. |
