Overview
The ABB CS513 is a communications module in the MasterBus 300E family, designed for ABB’s AC450 and AC460 control systems. It provides a robust Ethernet interface supporting IEEE 802.3 standards, enabling seamless integration with distributed control systems (DCS), SCADA platforms, and third-party automation equipment.
The CS513 supports both standard (MB300) and extended (MB300E) MasterBus configurations, selectable via onboard DIP switches. Its compact design and DIN-compatible mounting make it ideal for control cabinets with limited space.
For instance, in a thermal power plant, the CS513 can facilitate real-time communication between turbine controllers and the central monitoring system, ensuring synchronized operation and rapid fault response.
Technical Data
| Parameter | Specification |
|---|---|
| Model | CS513 |
| Part Number | 3BDE000435R1 |
| Dimensions (L × W × H) | 234 mm × 108 mm × 18 mm |
| Weight | 0.2 kg |
| Operating Temperature | –25°C to +55°C |
Typical Applications
-
Distributed Control Systems (DCS): Facilitates Ethernet communication between controllers and field devices.
-
SCADA Integration: Enables real-time data exchange with supervisory systems.
-
Power Generation Facilities: Supports turbine, boiler, and auxiliary system communication.
-
Chemical and Petrochemical Plants: Interfaces with process control units for safe and efficient operation.
-
Industrial Automation Networks: Provides reliable LAN connectivity for PLCs and I/O modules.
The CS513 is also commonly used in retrofit projects to upgrade legacy serial communication systems to modern Ethernet-based solutions.
FAQ
Q1: What systems is the CS513 compatible with?
A1: It works with ABB MasterBus 300E, AC450, and AC460 control systems.
Q2: What communication standard does it support?
A2: It supports IEEE 802.3 Ethernet for LAN-based data exchange.
Q3: Can I switch between standard and extended MB300 modes?
A3: Yes, DIP switches allow selection between MB300 and MB300E protocols.
Q4: Is it suitable for industrial environments?
A4: Absolutely. It operates from –25°C to +55°C and meets CE and RoHS standards.
Q5: What is the typical form factor?
A5: It measures 234 × 108 × 18 mm and mounts easily on DIN rails or panels.
