Product Description
The Yokogawa ADV157-S00 is a high-density 32-channel digital input module designed for the CENTUM VP Integrated Production Control System. As part of the FIO (Field network I/O) family, this module provides reliable acquisition of discrete signals from field devices such as valve positions, motor feedback contacts, and pressure switches.
Operating at 24 V DC, the ADV157-S00 supports both sink and source input configurations, offering compatibility with a wide range of industrial sensors. Its robust design features 2 kV AC isolation between field signals and the system backplane, ensuring protection against electrical noise, ground loops, and transient surges. The -S00 suffix indicates a standard-type module suitable for general-purpose automation applications.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | ADV157 |
| Suffix | -S00 (Standard Type) |
| Input Channels | 32 |
| Rated Logic Voltage | 24 V DC (Sink/Source compatible) |
| Input ON Voltage | 18.0 – 26.4 V DC |
| Input OFF Voltage | ≤ 5.0 V DC |
| Rated Input Current | 4.1 mA ±20% per channel |
| Signal Response Time | ≤ 8 ms |
| Isolation | 2 kV AC (Signal to System logic) |
| Commoning | 16 channels per common |
| Status Display | None (standard S/P type) |
| System Power Draw | 500 mA max at 5 V DC |
| Module Weight | 0.30 kg |
Functional Capabilities
-
High-Density Monitoring: 32 inputs per module maximize I/O density and minimize node unit footprint.
-
Signal Flexibility: Supports potential-free contacts (dry contacts) and voltage-generating sensors.
-
Robust Isolation: Protects the DCS backplane against field-side transients and surges.
-
Redundancy-Ready: Can be configured in dual-redundant FIO nests for uninterrupted input acquisition.
Industrial Applications
-
Process Monitoring: Captures status signals from pumps, valves, and limit switches.
-
Redundant Control Systems: Configured in redundant FIO nests to ensure continuous operation.
-
Marshalled Panels: Interfaces via pressure-clamp terminal blocks or KS multi-core cables to external I/O panels.
Technical FAQ
Q: How does the ADV157 differ from the ADV151?
A: Both are 32-channel modules, but the ADV157 is often used in specific node configurations or firmware revisions. Check ANB/ANT compatibility before deployment.
Q: Can this module be used in a redundant pair?
A: Yes, it supports dual-redundancy in a redundant FIO nest.
Q: How are the inputs wired?
A: Wiring is typically done via pressure-clamp terminal blocks or KS multi-core cables to an external marshalling panel, depending on the base unit used.
