Description
The Foxboro FBM207C P0917GY is a 16-channel contact sense input module for monitoring digital inputs.
Technical Specifications
-
Model: FBM207C P0917GY
-
Manufacturer: Foxboro
-
Function: Contact Sense Input Module
-
Channels: 16 isolated and independent channels
-
Pulse Count: No missing pulses for pulse rate 0 to 250 Hz
-
Filter/Debounce Time: Configurable (No Filtering, 4, 8, 16, or 32 ms)
Voltage Monitor Function
-
Logic One, On-State Voltage: 15 to 60 V DC
-
Logic Zero, Off-State Voltage: 0 to 5 V DC
-
Current: 1.4 mA (typical) at 5 to 60 V DC
-
Source Resistance Limits:
-
Logic One, On-State: 1 kΩ max at 15 V DC
-
Logic Zero, Off-State: 100 kΩ min at 60 V DC
Contact Sensor Function
-
Range (Each Channel): Contact open (off) or closed (on)
-
Open-Circuit Voltage: FBM207B 24 V DC ±15%; FBM207C 48 V DC ±15%
-
Short-Circuit Current: 3.2 mA typical
-
Logic One, On-State Resistance: 1.0 kΩ max
-
Logic Zero, Off-State Resistance: 100 kΩ min
| Quick Quotes | Receive price & availability FAST from our dedicated customer service team. |
|---|---|
| Delivery | Expedited, Freight, And International Shipping Available. |
| Condition | 100% New with Original Package |
| Payment | We accept American Express, Discover, MasterCard, PayPal, and Visa. Our site is secured by RapidSSL. |
| Shipping Port | ShangHai, Xiamen |
| Warranty | 12 Months |
| Q: Is Our Pricing Competitive? |
| A: Yes, we collaborate with over 50 countries worldwide. As a top supplier in China, we offer significant discounts based on market trends. |
| Q: What Is the Warranty Period? |
| A: All our new and original products come with a standard one-year warranty. |
| Q: What Payment Methods Do We Accept? |
| A: We require 100% T/T (Telegraphic Transfer) payment before shipping. For items with a lead time, a 30% deposit is needed upfront, and the remaining 70% is due before shipping. If you have a representative in China, you can arrange an RMB transfer through them. |
| Q: What Shipping Methods Do We Use? |
| A: We primarily use FedEx, DHL, UPS, and BRE for shipping. If you have an account with any of these carriers, you can handle shipping directly. We also offer free shipping to China-based freight forwarders. |
| Q: What Is Our Delivery Time? |
| A: Delivery usually takes 1-3 days after receiving the initial payment. For items with a lead time, shipping will occur according to the specified schedule. |
| Q: How Do We Package the Goods? |
| A: We ensure safe packaging with multiple layers of protection. Products are first placed in their original boxes and sealed with labels. A layer of bubble wrap is then added for collision protection during transit. Finally, the items are packed securely in durable boxes. |
| Q: How Can Customers Contact Us and Request a Quote? |
| A: You can reach out to us via email, WhatsApp, WeChat, Skype, or your preferred communication platform. Contact us with your needs, and we'll provide a prompt, customized quote. |
