The GE Fanuc IC754CGL06MTD-JH, also cataloged as the IC754CGL06MTD-JH Communication Module, operates as a dedicated hardware component for serial and network data exchange within Series 90-70 PLC control platforms.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | IC754CGL06MTD-JH |
| Brand | GE Fanuc |
| Origin | Subject to production batch |
| Weight | 0.5 kg |
| Dimensions | 241 mm x 40 mm x 110 mm |
| Operating Temp | 0 deg C to 60 deg C |
| Power Consumption | 500 mA at 5 VDC |
| Serial Interface | 1 x DB-9 (RS-232/RS-485) |
| Isolation | 500 VAC (logic to comms) |
| Baud Rates | 300 to 115,200 bps |
Industrial Control Deterministic Network Connectivity
The IC754CGL06MTD-JH is designed to manage deterministic data flow within Series 90-70 backplane architectures. Firmware flash compatibility ensures that the module maintains alignment with evolving serial communication requirements and protocol standards. The integration of high-speed buffers ensures that backplane bus communication velocity remains stable during high-traffic serial polling, while the galvanic isolation between logic and communication circuits protects internal processing stages from common-mode transients.
Frequently Asked Questions
Q: Does the module support hot-swapping during active backplane operation?
A: No. The IC754CGL06MTD-JH does not support hot-swapping. The PLC rack must be fully de-energized before module insertion or removal to prevent electrical shorting of the backplane connectors and potential damage to the control logic circuitry.
Q: Are there specific configuration requirements for the DB-9 interface?
A: Yes. The serial port supports configurable data formats (7 or 8 bits, parity options, 1 or 2 stop bits). Ensure that these parameters are synchronized with the external device settings via the PLC software to prevent frame errors and data corruption.
Field Installation Guidelines
- Ensure the module is firmly locked into the Series 90-70 rack slot using the front-panel mounting hardware to maintain electrical continuity with the backplane.
- Verify that the 5 VDC supply voltage is regulated within the ±5% tolerance range to prevent communication timeout errors.
- Use shielded, multi-conductor cables for serial connections, ensuring the shield is terminated at a single ground point to mitigate electromagnetic interference (EMI).
- Maintain a minimum distance of 50 mm between the communication cable and high-power AC lines to prevent induced signal jitter.
- Monitor the onboard LED status indicators during initialization to confirm proper handshaking and module health status.
