Product Overview
The Emerson Ovation 1B30023H01 I/O Bus Terminator Module plays a critical role in ensuring signal integrity within the Ovation Distributed Control System (DCS). This passive module is installed at the end of the I/O bus segment to prevent signal reflections that can corrupt data transmission. By maintaining the impedance matching, it ensures that high-speed digital signals travel cleanly across the backplane, which is essential for reliable communication in industrial control systems.
Without proper termination, signal reflections could lead to data errors or intermittent communication issues, making the 1B30023H01 a silent but vital component in any Ovation DCS setup.
Key Technical Specifications
| Specification | Detail |
|---|---|
| Model Number | 1B30023H01 |
| Category | I/O Bus Terminator Module |
| Function | Provides impedance matching to prevent signal reflection |
| Part Weight | 0.20 kg |
| Interface | Ovation Controller Backplane Bus |
| Installation Location | Installed at the end of the I/O bus segment |
Integration and Signal Integrity
The 1B30023H01 module integrates easily into the Ovation I/O backplane by plugging into the last available slot of the bus segment. Its passive resistor network ensures that:
-
Impedance matching is maintained to prevent signal reflections.
-
Communication signals remain clean, thus preventing intermittent errors in the data transmission.
-
The system's electrical health is maintained, ensuring the high-speed data exchange required by the Ovation DCS remains stable and reliable.
Its correct placement at the end of the I/O bus segment is essential for the stability and efficiency of the entire communication network.
Frequently Asked Questions (FAQ)
Q: What is the condition of the Emerson Ovation 1B30023H01 module?
A: The 1B30023H01 I/O Bus Terminator Module is brand-new and comes in original factory packaging.
Q: Is the 1B30023H01 module currently in stock?
A: Yes, we have the 1B30023H01 modules in stock and ready for immediate processing. Shipping typically takes 3 days to 2 weeks, depending on the order size and complexity.
Q: Which shipping methods do you use for the 1B30023H01?
A: We use reliable international logistics providers, such as DHL, to ensure secure and timely delivery.
Q: What is your return policy for the 1B30023H01 if there is a quality issue?
A: We offer a 30-day return policy for quality-related issues upon arrival.
Q: Where must the 1B30023H01 be physically installed in the Ovation system?
A: The 1B30023H01 module must be installed at the end of the I/O bus segment to correctly match impedance and prevent harmful signal reflections.
