Configured for protocol conversion in Versamax control networks, the GE Fanuc IC200SET001-EC (IC200SET001-EC Ethernet to Serial Network Module) provides direct physical/electrical execution. This hardware component mediates data exchange between Ethernet-based host controllers and legacy serial-based field devices by encapsulating serial data frames within Ethernet packets.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | IC200SET001-EC |
| Brand | GE Fanuc Emerson |
| Origin | Refer to device label |
| Weight | 0.25 lbs (0.11 kg) |
| Dimensions | Standard Versamax housing |
| Operating Temp | 0 to 60 deg C |
| Power Consumption | 5 VDC backplane powered |
| Function | Ethernet to Serial Gateway |
Profinet / EtherNet/IP Deterministic Networks
The IC200SET001-EC facilitates network integration by providing a bridge between high-speed Ethernet backplane communications and asynchronous serial protocols. The module manages packet buffering and serial-to-Ethernet translation, which introduces inherent protocol conversion latencies dependent on the configured baud rate and packet size. Deterministic performance on the Ethernet side is governed by the host controller's scan cycle and the configured TCP/IP or UDP/IP communication parameters. Users must account for the serial throughput constraints when calculating overall system response times for connected serial peripherals.
Frequently Asked Questions
Q: Does the module support simultaneous multi-protocol serial communication?
A: The module is designed to map specific serial configurations to Ethernet data streams. It does not perform complex multi-protocol routing; users must configure the serial port parameters (baud rate, parity, stop bits) to match the attached serial device.
Q: Is a firmware update required when transitioning between different serial device types?
A: Firmware compatibility is essential for maintaining communication stability. Users should verify that the installed firmware revision supports the specific serial framing requirements of the target device before deployment.
Field Installation Guidelines
- Verify that the Ethernet cable utilizes high-quality RJ45 connectors with proper strain relief to prevent intermittent signal loss during vibration.
- Ensure the serial cable shield is connected to the chassis ground at the device end to mitigate common-mode noise, which is common in serial data transmission.
- Follow standard RS-232 or RS-485 wiring conventions; ensure the TX and RX lines are correctly mapped according to the pinout diagram for the specific serial port connector.
- Do not exceed the maximum recommended cable length for the selected serial standard (e.g., 15 meters for RS-232, 1200 meters for RS-485) to prevent signal attenuation and data corruption.
- Route communication cabling through dedicated conduits, maintaining physical separation from power lines to avoid induced electrical noise.
