Product Overview
The IC693MDL655F is a high-density discrete input module for the GE Fanuc Series 90-30 PLC platform. It provides 32 input points for monitoring digital field devices such as proximity switches, limit switches, and push-buttons.
Its flexible design supports both sinking (negative logic) and sourcing (positive logic) configurations, allowing integration with a wide range of industrial wiring standards.
Technical Specifications
| Parameter | Specification |
|---|---|
| Input Channels | 32 (4 groups of 8) |
| Rated Voltage | 24 VDC |
| Input Voltage Range | 0–30 VDC |
| Input Current | 7.0 mA (typical at rated voltage) |
| Logic Type | Positive or Negative Logic (wiring/software dependent) |
| Isolation | Opto-coupler isolation (field to logic side) |
| Connectors | Two 24-pin male connectors (Groups A/B and C/D) |
| Internal Power Consumption | From +5 V backplane |
| Status Indicators | 32 LED indicators |
Engineering Advantages
High-Density Data Acquisition
32 channels in a single module maximize rack utilization, reducing system footprint and cost while increasing input capacity.
Bi-Directional Logic Flexibility
Supports both NPN (sinking) and PNP (sourcing) devices, reducing inventory requirements and simplifying system standardization.
Superior Signal Protection
Opto-isolation separates field wiring from the PLC backplane, protecting the CPU from electrical noise and voltage spikes.
Efficient Field Wiring Design
Dual 24-pin connectors divide inputs into structured groups, simplifying installation, wiring organization, and troubleshooting.
FAQs
Is this module brand new?
Yes, the IC693MDL655F is supplied as a 100% brand new original unit, fully tested to meet factory specifications.
What is the difference between positive and negative logic?
Positive logic means the field device sources voltage to the input, while negative logic means it sinks current to common. This module supports both depending on wiring configuration.
Can it be installed in any Series 90-30 rack?
Yes, it is compatible with all standard Series 90-30 baseplate I/O slots and communicates via the backplane.
How do the LED indicators help troubleshooting?
Each of the 32 LEDs shows real-time input status, allowing fast verification of field device operation without requiring a programming tool.
