Product Description
The PWB51549B is a specialized, high-performance printed circuit board engineered by Yokogawa for industrial instrumentation display management. This board functions as the critical interface between the system’s central processing unit and the LCD display, ensuring accurate, real-time visualization of process data in demanding industrial environments.
Key Features
-
Signal Processing: Optimized for high-speed data transmission to eliminate display lag and ghosting
-
Industrial Durability: Reinforced circuit paths designed to withstand electrical noise and cabinet-level vibration
-
Thermal Stability: Maintains reliable performance across extended operating temperatures for 24/7 operation
-
Compact Integration: Low-profile SMT components enable installation in space-constrained enclosures
Technical Specifications
| Item | Specification |
|---|---|
| Model Designation | PWB51549B |
| Primary Function | LCD interface and display control logic |
| Operating Temperature | –20°C to +60°C |
| Input Compatibility | Standard Yokogawa industrial voltage levels |
| Mounting Method | Multi-point screw mounting |
| Connector Type | High-density multi-pin headers |
| Construction | Lightweight composite PCB design |
Industrial Applications
The PWB51549B is commonly installed in Yokogawa proprietary display systems, including:
-
Human-Machine Interfaces (HMI)
-
Paperless recorders
-
Industrial operator panels
It is a key spare part for maintenance teams in power generation, water treatment, and chemical processing facilities where continuous and accurate visual feedback of process variables is essential.
Technical FAQ
Q: Is the PWB51549B a standalone display controller?
A: No. It is an integrated display interface board that must be connected to a compatible Yokogawa processor unit for data and power.
Q: Does this board require dedicated firmware?
A: The board itself operates as a hardware interface. Display behavior and graphics are governed by the firmware on the connected system controller.
