Overview
The ProvibTech TM202 series is designed for vibration protection and monitoring in turbines, compressors, pumps, and other rotating machinery.
The TM202-A00-B00-C00-D00-E00-F00-G00 configuration specifies probe type, cable length, connector style, driver, and transmitter options, providing a modular system that supports flexible installation and integration into PLC, DCS, and SCADA systems.
The Transmission Table is a configuration code breakdown, where each suffix (A00, B00, etc.) corresponds to a specific mechanical or electrical option, allowing customized setups for various machinery and monitoring requirements.
Transmission Table (Configuration Breakdown)
| Code Segment | Meaning / Example |
|---|---|
| A00 | Probe type – standard 8 mm eddy current probe |
| B00 | Armor type – non‑armored cable |
| C00 | Case length – 30 mm standard |
| D00 | Cable length – 1.0 m typical |
| E00 | Connector type – standard industrial connector |
| F00 | Driver type – standard TM0181 driver |
| G00 | Transmitter type – TM202 vibration transmitter, 4–20 mA output |
Technical Data
| Parameter | Specification |
|---|---|
| Model | TM202-A00-B00-C00-D00-E00-F00-G00 |
| Product Type | Vibration Transmitter |
| Operating Temperature | -40 °C to +85 °C |
Typical Applications
-
Continuous vibration monitoring of turbines, compressors, and pumps.
-
Integration with PLC/DCS systems for automated machine health diagnostics.
-
Predictive maintenance programs in power generation, oil & gas, and petrochemical industries.
-
Shaft vibration and position monitoring in large rotating machinery.
FAQ
Q1: What does the Transmission Table represent?
A1: It is a configuration code that defines probe, cable, connector, driver, and transmitter options for modular customization.
Q2: What is the output signal of the TM202 transmitter?
A2: A standard 4–20 mA DC signal proportional to vibration amplitude.
Q3: Is it compatible with TM0180 probes?
A3: Yes, it works with TM0180 proximity probes and TM0181 extension cables.
Q4: What industries typically use this transmitter?
A4: Power generation, oil & gas, petrochemical, and heavy machinery sectors.
Q5: How does it support predictive maintenance?
A5: By continuously monitoring vibration levels, it provides early warnings of imbalance, misalignment, or bearing wear.
