Product Overview
The IC695ALG508-EB is a high-precision 8-channel RTD and resistance input module for the Emerson (GE Fanuc) PACSystems RX3i platform. It supports multiple RTD types and direct resistance measurement with full channel isolation, ensuring accurate temperature acquisition in electrically noisy environments. Supplied as 100% Brand New original equipment.
Technical Specifications
| Parameter | Specification |
|---|---|
| Channels | 8 isolated differential |
| Sensor Types | Platinum, Nickel, Copper, Nickel-Iron RTDs |
| Resistance Ranges | 0–260 Ω up to 0–4200 Ω |
| Wiring Types | 2-wire, 3-wire, 4-wire |
| Data Format | 16-bit integer / 32-bit floating point |
| Notch Filter | 2.3 Hz to 28 Hz selectable |
| Operating Temp | 0°C to 60°C |
| Weight | 0.26 kg |
Engineering Advantages
Channel Isolation
Prevents cross-channel interference, improving reliability in critical monitoring systems.
Wide Sensor Support
Compatible with multiple RTD types, reducing the need for different module variants.
Flexible Wiring Options
Supports 2/3/4-wire configurations for varying accuracy and installation requirements.
Noise Filtering Control
Selectable filters help suppress 50/60 Hz electrical noise for stable readings.
FAQs
What terminal blocks are required?
A 36-terminal block such as IC694TBB032 or IC694TBS032 is required.
What happens during CPU failure?
Each channel can be configured to hold last value or switch to a preset fail-safe value.
Can different sensor types be mixed?
Yes, each channel can be independently configured for different RTD or resistance inputs.
