Product Description
The Triconex 2211 is a high-precision analog input module designed for integration within the Tricon Triple Modular Redundancy (TMR) system. Engineered for mission-critical safety and control applications, this module supports 32 differential, DC-coupled input channels, delivering excellent signal isolation, noise immunity, and measurement stability.
With a fast 10 ms update rate and user-selectable resolution, the Triconex 2211 enables accurate, real-time acquisition of voltage signals in demanding SIL-rated Safety Instrumented Systems (SIS). Its robust electrical protection and strong common-mode rejection ensure reliable performance even in harsh, electrically noisy industrial environments.
Key Features
-
32 differential, DC-coupled analog input channels
-
High-speed data acquisition with 10 ms update rate
-
Supports unipolar and bipolar voltage input ranges
-
Programmable measurement resolution (12-bit or 14-bit)
-
Excellent noise immunity with high common-mode suppression
-
Rugged design with strong over-voltage protection
Technical Specifications
| Parameter | Specification |
|---|---|
| Input Configuration | 32 differential channels, DC coupled |
| Input Voltage Range | 0 to 5 VDC or ±5 VDC |
| Measurement Resolution | 12-bit or 14-bit (user programmable) |
| System Accuracy | 0 °C to 60 °C |
| Processing Speed | 10 ms update rate (all points) |
| Common Mode Suppression | –85 dB (DC to 100 Hz) |
| Module Weight | 1.36 kg |
Applications
-
Safety Instrumented Systems (SIS)
-
Emergency Shutdown Systems (ESD)
-
Burner Management Systems (BMS)
-
Turbine and compressor protection
-
High-precision voltage signal monitoring
