Product Description
The AAI141-H50/K4A00 is a high-performance analog input module for the Yokogawa CENTUM VP system. It provides 16 input channels for accurate acquisition of 4–20 mA current signals or 1–5 V DC voltage signals from field transmitters.
The module supports HART digital communication, enabling remote configuration, diagnostics, and device monitoring. This variant includes the /K4A00 KS cable interface, allowing quick and reliable connection to terminal boards using prefabricated KS cables, significantly simplifying cabinet wiring.
Technical Specifications
| Parameter | Specification |
|---|---|
| Input Channels | 16 channels, non-isolated |
| Signal Types | 4–20 mA DC or 1–5 V DC |
| HART Communication | Supported |
| Accuracy (Current) | ±16 μA |
| Accuracy (Voltage) | ±4 mV |
| Transmitter Power Supply | ≥14.8 V @ 20 mA; ≤26.4 V @ 0 mA |
| Input Resistance (Power ON) | 400–1000 Ω (current-dependent) |
| Input Resistance (Power OFF) | ≥500 kΩ |
| Data Update / Response | 10 ms update, 100 ms step response |
| Temperature Drift | ±16 μA / 10 °C (current); ±4 mV / 10 °C (voltage) |
| Power Consumption | 310 mA @ 5 V DC; 450 mA @ 24 V DC |
| Weight | 0.2 kg |
Application Scenarios
The AAI141-H50/K4A00 is well suited for high-density signal monitoring in centralized control rooms where field instruments share a common grounding reference. Typical applications include factory automation, power plant monitoring, and utility systems, where the integrated transmitter power supply reduces reliance on external loop power supplies for 2-wire transmitters.
Technical FAQ
Q: Can this module power both 2-wire and 4-wire transmitters?
A: Yes. The module supports 2-wire (loop-powered) and 4-wire (self-powered) field devices through configuration settings.
Q: What is the difference between AAI141 and AAI143?
A: AAI141 uses non-isolated channels, making it a cost-effective solution for stable grounding environments. AAI143 provides full channel isolation for applications requiring enhanced noise and ground-loop protection.
Q: What cabling is required for the /K4A00 option?
A: The /K4A00 variant uses a KS cable interface, typically requiring Yokogawa KS1 or KS2 cables to connect the module to the terminal board.
