Product Overview
The S9341FA is a connector unit with integrated terminator designed for the Yokogawa CENTUM series DCS, specifically for the Extended Serial Backplane (ESB) Bus. It provides the physical connection for ESB bus cables and incorporates a built-in bus terminator, ensuring signal integrity by preventing reflections at the end of the communication line. This enables reliable, high-speed data transmission between Field Control Units (FCU) and associated I/O expansion units.
Technical Specifications
| Item | Description |
|---|---|
| Model Number | S9341FA |
| Component Type | Connector Unit with Integrated Terminator |
| Bus Compatibility | ESB Bus (Extended Serial Backplane) |
| System Integration | CENTUM VP, CENTUM CS 3000 |
| Termination Resistance | Standardized for ESB Bus impedance matching |
| Cable Connection | Supports standard ESB Bus communication cables (e.g., YCB301) |
| Signal Protection | Shielded design minimizes EMI |
| Mounting | Direct attachment to ESB Bus interface port of an I/O node |
| Operating Temperature | 0°C to 50°C |
Functional Importance & Application
-
Signal Reflection Suppression: Terminates the ESB bus to prevent reflections that cause data corruption or communication errors
-
Network Extension: Enables FCUs to communicate with multiple I/O nests across control cabinets or adjacent locations
-
Ease of Installation: Combines connector and terminator in a compact unit, reducing wiring complexity and potential failure points
FAQ
Where should the S9341FA be installed?
It must be installed on the last I/O expansion node in an ESB bus chain, signaling the electrical end of the bus.
Can it be used with the ER Bus?
No. The S9341FA is designed specifically for the ESB Bus. The ER Bus uses different connectors and termination requirements, typically S9157FA or similar.
