Product Overview

The Emerson CL6824X1-A1 Analog Input/Output Module is engineered for reliable signal acquisition and control in industrial automation systems. Designed for seamless integration with the DeltaV DCS platform, this module supports both current and voltage analog signals, enabling flexible connectivity with field instruments such as transmitters, sensors, and actuators.

Moreover, the module offers 16-bit resolution, ensuring high signal fidelity for critical applications. In addition, its compact DIN rail-mountable design simplifies installation in control cabinets, while its CE certification guarantees compliance with international safety standards.

Therefore, the CL6824X1-A1 is a trusted solution for engineers seeking robust analog I/O performance in industries such as oil & gas, chemical processing, and power generation.

Technical Specifications

Typical Applications

The CL6824X1-A1 module is widely used in industrial automation systems requiring precise analog signal control. For instance:

• Oil & Gas: Monitors pressure and temperature transmitters while controlling modulating valves

• Chemical Processing: Interfaces with flowmeters and dosing pumps in corrosive environments

• Power Generation: Manages analog feedback from turbines and boiler systems

• Pharmaceuticals: Supports validated process control with high signal accuracy

• Water & Wastewater: Regulates level sensors and pump control in distributed SCADA systems

In addition, its dual I/O capability reduces module count and simplifies wiring in distributed control architectures.

System Integration Experience

The CL6824X1-A1 integrates seamlessly with Emerson’s DeltaV DCS platform, supporting modular expansion and open communication protocols. Moreover, its rugged design and wide operating temperature range make it suitable for deployment in harsh industrial environments.

Therefore, system integrators benefit from flexible deployment, enhanced diagnostics, and long-term reliability in mission-critical applications.

FAQ

Q: What signal types does the CL6824X1-A1 support?
A: It supports 4–20mA and 0–10V analog signals for both input and output.

Q: How many channels are available?
A: It includes 8 analog input channels and 4 analog output channels.

Q: Is it compatible with DeltaV systems?
A: Yes, it is designed for seamless integration with Emerson’s DeltaV DCS.

Q: What’s the operating temperature range?
A: It functions reliably from –40°C to +85°C.

Q: What industries use this module?
A: Oil & gas, chemical, pharmaceutical, power generation, and water treatment sectors.
