Overview

The AGC‑242 is part of DEIF’s AGC‑200 series of advanced genset controllers. It is designed to manage, protect, and synchronise generator sets in applications ranging from stand‑alone gensets to multi‑genset power plants. With integrated communication, protection, and monitoring features, it is widely used in marine, industrial, and utility power systems.

Technical Specifications

Key Features

• Automatic synchronisation: Seamless generator paralleling.

• Advanced load sharing: Isochronous and droop control for balanced power distribution.

• Comprehensive protection: Covers reverse power, overcurrent, voltage/frequency deviations, and more.

• Flexible communication: Supports Modbus, CANopen, and J1939 protocols.

• User-friendly interface: Graphical LCD for configuration and monitoring.

• Rugged design: Wide operating voltage and temperature range suitable for harsh environments.

Typical Applications

• Marine power systems with multiple gensets in parallel.

• Industrial plants requiring reliable backup and distributed generation.

• Utility and microgrid installations needing synchronisation and load sharing.

• Emergency power systems with automatic mains failure (AMF) functionality.

FAQ

Q1: What makes the AGC‑242 different from simpler genset controllers?
A1: It integrates synchronisation, load sharing, and advanced protection, making it suitable for multi‑genset and complex installations.

Q2: Can it communicate with SCADA systems?
A2: Yes, via Modbus RTU/ASCII, CANopen, and J1939 protocols.

Q3: What protection functions are included?
A3: It covers over/under frequency, over/under voltage, overcurrent, reverse power, and more.

Q4: Is it suitable for marine use?
A4: Yes, it is widely deployed in marine genset applications.

Q5: What is the operating voltage range?
A5: It supports 18–72 VDC, with nominal operation at 24/48 VDC.
