Product Overview
The IC695CHS012CA is a 12-slot Universal Backplane for the PACSystems RX3i platform. It serves as the core structural and electrical foundation of the system, supporting both high-speed PCI-based modules and legacy-compatible RX3i/Series 90-30 modules within a single chassis.
Designed for large-scale automation systems, this backplane provides flexible module placement, high I/O density, and robust electrical distribution. We supply this unit as 100% Brand New original stock, ensuring full system integrity and reliable long-term operation.
Technical Specifications
| Parameter | Specification |
|---|---|
| Number of Slots | 12 |
| Module Compatibility | IC695 (PCI), IC694 (serial), IC693 (Series 90-30) |
| Backplane Bus | Dual bus (PCI + serial) |
| Mounting Type | Panel mount |
| Internal Current Capacity | Supports RX3i high-capacity power supplies |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Weight | 1.81 kg |
Engineering Advantages
Dual-Bus Architecture
Combines a high-speed PCI bus for modern modules (Ethernet, motion, advanced control) with a serial bus for legacy I/O, enabling mixed-system integration within a single rack.
Universal Slot Flexibility
Most slots support CPUs, power supplies, and I/O modules interchangeably, allowing optimized layout for wiring, airflow, and system scalability.
Migration-Friendly Design
Supports integration of legacy Series 90-30 modules, enabling gradual system upgrades without full hardware replacement.
Industrial-Grade Mechanical Structure
Built for harsh environments with reinforced grounding points and vibration-resistant construction to maintain stable signal integrity across all slots.
FAQs
Does this backplane include a power supply?
No. The IC695CHS012CA is the chassis only. A compatible RX3i power supply (such as IC695PSD040 or IC695PSD140) must be installed separately.
Where should the CPU be installed?
The CPU can be placed in any universal slot, though slot 1 or 2 is typically used for standard configuration and system organization.
What does the “-CA” suffix mean?
It indicates a specific hardware revision/production standard. This unit is 100% Brand New, incorporating the latest manufacturing updates.
Can this backplane be expanded?
Yes. It supports expansion and remote racks via RX3i expansion modules and cables (e.g., IC695CHS007), allowing distributed system architectures.
