Product Overview
The Honeywell 51304286-100 is a rugged, non-contact rotary position sensor designed for use in demanding industrial and mobile equipment applications. Utilizing advanced magnetic resistive (MR) technology with integrated ASICs, it accurately detects absolute angular position over a range of 0° to 145°. The sensor features a CAN-2.0B SAE J1939 output for smooth integration into modern control networks. Engineered for reliability in harsh environments, it is housed in a sealed enclosure rated IP68/IP69K, making it ideal for transportation, military, and aerospace sectors. With no physical contact required, the sensor offers low maintenance and long service life even under extreme shock and vibration conditions.
Technical Specifications
| Specification | Details |
|---|---|
| Model Number | 51304286-100 |
| Sensor Type | Non-contact rotary position sensor |
| Sensing Range | 0° to 145° |
| Output Signal | CAN-2.0B SAE J1939 |
| Connector Type | Deutsch DT06-04 |
| Technology | Magnetic resistive (MR) with ASIC integration |
| Ingress Protection | IP68 / IP69K |
| Linearity | ±0.3% over full range |
| Operating Voltage | 5 VDC |
| Weight | 0.35 lbs (approx. 159 g) |
| Dimensions | 13.4 × 8.5 × 1.5 cm |
| Temperature Range | -40°C to +85°C |
| Shock Resistance | High-impact rated |
| Vibration Resistance | Designed for mobile machinery |
| Mounting Tolerance | 5.25 mm air gap |
| Certifications | CE, UL508, CSA, RoHS compliant |
| Warranty | 12 months |
| Country of Origin | United States |
