Product Overview
The Emerson Ovation 1C31222G01 is a high-power Relay Output Base Module designed for use within the Emerson Ovation Distributed Control System (DCS). This module provides critical switching capability for industrial loads by converting low-voltage control signals into high-current commands for actuators, motors, and other heavy-duty devices. With its robust construction and proven reliability, the 1C31222G01 ensures continuous and dependable performance in demanding power generation and process automation environments.
Robust Design and High Channel Capacity
Engineered for rugged industrial applications, the 1C31222G01 features 16 independent relay outputs, offering exceptional density for multi-point control. Each channel is rated for 30 A at 250 VAC, providing ample capacity for heavy loads. The relay contacts are made of silver cadmium oxide, which enhances durability, minimizes contact wear, and extends operational life.
Additionally, the module maintains reliable performance across a wide operating temperature range—from −40°C to +70°C—making it ideal for mission-critical systems that demand stability under harsh environmental conditions.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | Relay Output Base Module |
| Part Number | 1C31222G01 |
| Operating Temperature | −40°C to +70°C |
| Dimensions (L x W x H) | 42.4 cm × 12.6 cm × 10.8 cm |
| Weight | 0.8 kg |
Key Features
-
High Power Output: Each channel supports up to 30 A at 250 VAC.
-
16-Channel Design: Enables high-density control in limited cabinet space.
-
Rugged Construction: Designed for reliable use in extreme industrial environments.
-
Durable Contacts: Silver cadmium oxide relays extend service life.
-
Wide Operating Range: Performs consistently from −40°C to +70°C.
-
Compact Form Factor: Space-efficient installation within control cabinets.
-
Seamless Integration: Fully compatible with Emerson Ovation DCS and Westinghouse PLC systems.
FAQ
Q: What is the maximum current rating per channel for the 1C31222G01 module?
A: Each of the 16 relay outputs can handle up to 30 A at 250 VAC, supporting high-power switching applications.
Q: How many relay output channels does the 1C31222G01 provide?
A: The module provides 16 independent relay outputs, offering excellent output control density.
Q: What is the operating temperature range for the Emerson 1C31222G01?
A: It operates reliably between −40°C and +70°C, ensuring dependable performance in industrial environments.
