Product Overview
The Woodward DECS-100-B15 is a high-performance Digital Excitation Control System engineered specifically for synchronous generators. This module manages the exciter field current to regulate output voltage, ensuring stable power delivery across a wide range of load conditions. The DECS-100-B15 is the primary control unit for generator synchronization, making it essential for grid stability in industrial power generation systems.
Technical Specifications
| Specification | Details |
|---|---|
| Model Number | DECS-100-B15 |
| Condition | 100% Brand New, Original Packaging |
| Input Power | 120 Vac or 240 Vac (Single or Three Phase) |
| Continuous Output Current | 7 Adc |
| Forcing Output Current | 11 Adc (for 10 seconds) |
| Regulation Accuracy | ±0.25% (No load to full load) |
| Frequency Range | 50 Hz or 60 Hz (Programmable) |
| Operating Temperature | -40°C to +70°C |
Engineering Advantages
-
Advanced Noise Immunity: The DECS-100-B15 integrates EMI filtering, providing resistance to high-frequency interference. This ensures stable voltage regulation, even when installed near high-power switching gear or variable frequency drives.
-
Comprehensive Protection Suite: The module continuously monitors critical generator parameters. In case of over-excitation, under-excitation, or over-voltage, the system triggers automatic shutdowns or limiters to prevent catastrophic damage to the generator.
-
Simplified Commissioning: The DECS-100-B15 is easily configured using Woodward’s intuitive PC software. The RS-232 port enables quick uploading of PID settings and setpoints, minimizing onsite startup time and eliminating the need for manual adjustments.
-
Ruggedized Thermal Management: The module’s potting compound efficiently dissipates heat, making it suitable for use in poorly ventilated generator terminal boxes without risk of thermal derating.
FAQs
Can the DECS-100-B15 operate in parallel with other generators?
-
Yes. The module supports features like reactive droop compensation and cross-current compensation, allowing multiple generators to share the reactive load proportionally, without causing circulating currents.
How do I verify the authenticity of this module?
-
Each unit comes in original factory packaging with a verified serial number and manufacturer's certificate. Only 100% brand-new components are supplied to meet Woodward’s performance specifications.
Does this unit support Manual Control mode?
-
Yes. The DECS-100-B15 includes a Manual (Field Current) Regulation mode, which allows operators to bypass automatic voltage regulation during troubleshooting or special testing procedures.
What software is required for configuration?
-
Technicians use Woodward’s proprietary DECS-100 software suite to configure the system. The software provides real-time metering and full access to the module’s internal logic for fine-tuning the excitation curve.
