Product Description
The FBM214/216 (P0926EJ-0C) is an 8-channel isolated HART analog input module for Foxboro I/A Series and Evo systems. It acquires 4–20 mA signals while simultaneously providing HART digital communication, enabling diagnostic and asset management data collection. Each channel features galvanic isolation to protect the system bus from electrical noise and ground loops, and the module can supply loop power to two-wire transmitters.
Technical Specifications
| Parameter | Specification |
|---|---|
| Module Type | Isolated HART Analog Input |
| Model | FBM214/216 |
| Part Number | P0926EJ-0C |
| Operating Temp | –20°C to +70°C |
| Dimensions (W×H×D) | 2.2 × 12.4 × 12.6 cm |
| Weight | 0.17 kg |
Application
-
Pressure, temperature, and flow monitoring with HART diagnostics
-
Two-wire transmitter loop-powered installations
-
Asset management and device health monitoring in critical loops
Notes
-
FBM214 vs FBM216: Same hardware; FBM214 for standard tasks, FBM216 for redundancy or advanced diagnostics
-
Supports point-to-point HART; can work with externally powered 4-wire transmitters
