The GE Fanuc IC200UEX626-D, also cataloged as the IC200UEX626-D Analog Expansion Module, operates as a dedicated hardware component for multi-range signal processing within VersaMax Micro platform networks.
Hardware Specifications
| Parameter | Specification |
| Model | IC200UEX626-D |
| Brand | GE Fanuc |
| Origin | Subject to factory batch |
| Weight | 0.425 kg |
| Dimensions | 101.6 x 88.9 x 50.8 mm |
| Operating Temp | 0 deg C to 60 deg C |
| Power Consumption | 3 W |
| Analog Inputs | 4 differential (0–10 VDC, ±10 VDC, 0–20 mA, 4–20 mA) |
| Analog Outputs | 2 single-ended (0–10 VDC, 0–20 mA, 4–20 mA) |
| Resolution | 12-bit |
Backplane Bus Communication and Firmware Compatibility
The module integrates via the expansion port to provide real-time signal conversion for the host controller. The backplane bus communication velocity is optimized to ensure low-latency data acquisition, allowing the module to report analog values within the scan cycle. Firmware flash compatibility is managed by the host system to ensure alignment with existing project configurations. The module utilizes high-density I/O density scaling techniques to process multiple signal types simultaneously, ensuring consistent accuracy across all 6 channels.
Frequently Asked Questions
Q: Can this module be installed at a distance from the host controller?
A: The module supports remote installation at distances up to 2 meters using the manufacturer-specified expansion cabling.
Q: Are the analog inputs galvanically isolated from the controller?
A: The inputs are designed with differential architecture to mitigate common mode noise up to ±40 V, but users should verify grounding requirements to maintain signal integrity.
Field Installation Guidelines
- Mount the module securely on a DIN rail or flat surface using the integrated mounting points.
- Utilize shielded, twisted-pair cabling for all analog signals to minimize electromagnetic interference and crosstalk.
- Connect the cable shield to a single point chassis ground at the cabinet entry to maintain signal common mode rejection.
- Ensure the 24 VDC power supply operates within the 19.2–30 VDC range to prevent operational instability.
- Inspect the diagnostic LED indicators during power-up to confirm the module is communicating correctly with the host controller.
- Confirm that the voltage or current range switches are set correctly for each channel before applying field signals.
