Product Overview
The GE Fanuc IC693MDL742J is a 12/24VDC, 0.5A positive logic (sourcing) digital output module for Series 90-30 and PACSystems RX3i platforms. It provides 16 output points for controlling devices such as solenoids, relays, and indicators. The “J” revision includes built-in electronic short circuit protection. Supplied 100% brand new, factory sealed.
Technical Specifications
| Specification | Details |
|---|---|
| Nominal Voltage | 12/24 VDC |
| Voltage Range | 12–24 VDC (+20%, –15%) |
| Output Points | 16 (single group) |
| Output Current | 0.5A per point (2A per common) |
| Logic Type | Positive Logic (Sourcing) |
| Inrush Current | 5.4A for 10ms |
| Response Time | 2 ms max (ON/OFF) |
| Protection | Electronic Short Circuit Protection (ESCP) |
| Weight | 0.32 kg |
Engineering Advantages
-
Built-in ESCP protection reduces risk of permanent damage from short circuits
-
Low heat generation enables high-density cabinet installation
-
Dual-platform compatibility supports both Series 90-30 and RX3i systems
-
LED diagnostics provide fast visual status of each output point
FAQs
What does the “J” revision mean?
It adds electronic short circuit protection and improved hardware reliability.
Can it switch both 12V and 24V loads?
No, all outputs share one common voltage—only one level should be used per module.
How is a short circuit reset?
Clear wiring fault, then cycle output or power to reset protection.
What terminal block is used?
IC693ACC311 20-terminal block is typically required.
